February is here. Winter is in full swing on this side of the equator. Summer is grasping the other. I know it’s been a warm one so far for our friends in Australia. But snowfall amounts in the Northeast has our ski areas in Northern California and the Rockies so envious. Such is Mother Nature right?
Recently, our team announced some important details for our Switching and Wireless products.
I thought I would take the time to let you all know more on these announcements.
First up, Nasser Tarazi, Wireless Product Manager, announced two new models. We will cover the new WAP351 this week and the new WAP131 next week.
The New Cisco WAP351
The new Cisco WAP351 perfect for conference rooms, classrooms, hospitality and other flexible deployments. It offers Dual Radio (2.4Ghz and 5Ghz) wireless N connectivity, a 5-port Switch with PoE PD and PSE support, Single Point Setup, Captive Portal and comes with Limited Lifetime Warranty.
The WAP351 offers something new to the Wireless portfolio. Here is a quick Power Over Ethernet (PoE) primer. PoE Powered-Device (PD) is the ability to power the device through an PD-capable Ethernet port. PoE PSE (Power Sourcing Equipment) is the ability to supply power a device connected to a PSE-capable Ethernet port. In terms of power, a standard PoE port can support a maximum output of 15W, while a PoE+ port supports up to 30W.
Now, back to the WAP351. As mentioned above, the WAP351 support both PD and PSE. This means if the WAP351 is connected to a PoE+ switch like the SG300-10PP, the WAP351 can be power through PD-capable Ethernet port, while at the same time powering a standard PoE device like a phone or another AP, like the WAP131 through the WAP351’s designated PSE-capable Ethernet port.
More on Wireless Access Points and PoE:
- PoE: Power over Ethernet. PoE enables Power and Data to be combined onto a single Ethernet cable to power devices such as access points, IP phones, or IP cameras
- PSE on a WAP is exclusive to the new WAP351
- A WAP with PSE is attractive for verticals such as education, hospitality, and smaller offices and meeting rooms where both wired and wired access is required
- PoE enables WAP’s or other endpoint devices to be installed where power typically is not available, such as on a wall or ceiling. This allows for greater flexibility during deployments.
- All Cisco Small Business WAP’s support PoE PD
- Dual-Radio WAPs requiring 802.3af PoE power = WAP131, WAP351, WAP561
- Dual-Radio WAPs requiring 802.3at PoE+ power = WAP371, WAP351 when using the PSE with full power budget
- The WAP351 can be powered by 48V/1.25A external DC power if a 802.3af/t PoE switch is not used or available
- The WAP351 can provide 6w of PSE when using 802.3af
Ok you got it? Make sense?
Cisco 300 Series Switches
In other news:
Switching Product Manager Michael Wynh announced several price reductions on the ever-popular 300 Series Switches. This is good news for our customers and channel partners alike. Businesses can maximize their budgets and take advantage of Cisco’s class-leading PoE switching products. For more information on these important updates, please contact your local Cisco Representative or check out our support community.
That is it for now. Thanks for hanging out with us.
Until next time,
Tags: #wireless, access point, Cisco, Cisco Wireless, ethernet, network, PoE ports, port, router, switch, VLAN, wlan
Note: This blog was simultaneously published on the SNIA blog.
When I first started in storage technology (it doesn’t seem like that long ago, really!) the topic seemed like it was becoming rather stagnant. The only thing that seemed to be happening was that disks were getting bigger (more space) and the connections were getting faster (more speed).
More speed, more space; more space, more speed. Who doesn’t like that? After all, you can never have too much bandwidth, or too much disk space! Even so, it does get rather routine. It gets boring. It gets well, “what have you done for me lately?”
Then came Flash. Read More »
Tags: ethernet, FCoE, Fibre Channel, flash, NAND, NVMe, PCIe, SSDs
It is Friday the 13th and we have a full moon, perfect time to provide a quick update from the Cisco SMB Team.
First off, we have posted a Teaser Announcement providing a quick view of some new products that are coming out later this month. The entire Cisco SMB Team has been working hard on this new launch so look for more information that will be coming out.
220 Smart Plus Series
The Switching Team currently has a cisco.com for the new 220 Smart Plus Series.
Ivor Diedricks posted a new Blog earlier this month called Understanding the different types of Ethernet Switches. He explains the differences between fixed and modular switches, and goes into the details of what makes an Unmanaged, Smart and Fully Managed models. It is a good read, if you haven’t already, please take a look.
Finally, I have a new RV325 emulator on our Cisco Emulator Page. These emulators provide you the chance to take a test drive through our device user interface. You can take a look at our easy-to-use configuration wizards, configure features such as VLAN’s, Single-Point-Setup on our Wireless Access Points, and even configure VPN’s on the routers.
Make it a safe Friday the 13th!
Tags: blog, business, emulator, ethernet, Flexibility, Manage, network, PoE ports, PoE+, rout, scalable, small, spatial stream, switch, VLAN, vpn, wireless
Written By Amrit Hanspal, Senior Manager, Service Provider Lead, Network OS Tech Group
Cisco Live in San Francisco (next week!) offers a host of learning opportunities if you are part of a Service Provider, or a large Enterprise that offers services to internal groups. Let my blog be your guide to help you chart out all the different sessions that Cisco has to offer during the week, with a specific focus on the software capabilities of the routing and switching platforms in 4 key areas – IPv6, SDN, MPLS Transport & Ethernet Services, and IP Routing.
First up, IPv6! The exhaustion of IPv4 is not the only driving force for IPv6 adoption. Service Provider IPv6 deployments are rapidly ramping up with a majority of SPs looking towards IPv6. Join us for a recap on ‘IPv6 – From Intro to Intermediate’ (Session ID: BRKRST-2116) or join us to hear about our experiences in ‘Service Provider IPv6 Deployment’ (Session ID: BRKSPG-3300) where our IPv6 gurus highlight deployment best practices and real-world challenges. Security is key in IPv6 – and that’s the focus of ‘IPv6 Security Threats & Mitigations’ (Session ID: BRKSEC-2003). And since we are dealing with the networking, don’t worry, we got you covered with a Troubleshooting IPv6 session (Session ID: BRKRST-2304). See the full list of learning opportunities at here.
Next up, is SDN – Software Defined Networking. The industry’s latest Read More »
Tags: cisco live, ethernet, IP routing, IPv6, mpls, SDN, Service Provider
Quality wireless is already considered a base expectation by consumers across industries. At Cisco we aim to provide our spectrum of customers with a whole range of high performing products, so they can select the product best suited for their organization. If you were to stop by the Enterprise Networking booth at Cisco Live Milan, you’d be able to examine our full portfolio of access points and notice that there are two that stand out from the others: the newly designed, 802.11ac integrated 3700 AP we introduced at Interop New York and one more, except this one can fit in your hand.
We are pleased to announce Cisco Aironet 700W Series Access Point, a wall mounted wireless and wired integrated platform. 700W Series is the industry’s FIRST and ONLY dual radio, dual band 2.4/5 GHz Access Point with 4 GigE Ethernet ports for wired connectivity, like IP Phones, game consoles, entertainment devices or other connected devices. 700W Series can be powered either by Power over Ethernet (PoE) or by a local power adapter, while it also provides PoE out on one local port to power an additional connected device. Read More »
Tags: #CLEUR, access point, AP, bracket, cells, Cisco, cisco live, deployment, design, device, Dual Band, ethernet, form factor, GHz, GigE, high density, local port, mobile, mobility, PoE+, power adapter, Power over Ethernet, Prime Infrastructure, right-sized, roaming, RRM, wi-fi, wifi, wireless
