In today’s highly mobile society we try to stay as connected as we possibly can, whether that be for instant messaging, email, or keeping up with our favorite TV shows and movies. This obsession for connectivity has stressed the wireless infrastructures that are installed by many organizations. Because of this many organizations are looking to update their systems that support 802.11n technologies or even the older 802.11a/b/g standards. As a consultant it is one of my jobs to help a customer understand the new technology inside and out and make sure their networks are deployed accordingly. One of the major topics discussed when going over 802.11ac is throughput. 802.11ac brings with it a substantial jump in throughput, but there is a price to pay in order to achieve those higher data rates.
Let’s go over a basic first, in wireless technology we use a frequency, or channel, to send our signal from the client to the station (access point). Think of this channel as a lane on a highway or freeway. A single lane carries so many cars per hour. Now if we add another lane in the same direction we can carry double the amount of traffic. This is repeated for each lane that you add. 802.11n and 802.11ac both allow us to combine multiple lanes to act as a single wide lane, allowing for larger traffic to pass. These channels are reflected as 20MHz, 40MHz (2 lanes – 802.11n and 802.11ac), and 80MHz (4 lanes – 802.11ac).
Ok, so we get the hole channel concept now right? So what’s the big deal then if we start combining these channels? Channels = capacity in the wireless world. A channel only has so much bandwidth to provide, you can’t create more, it’s a very finite resource. When our goal is to support hundreds of client devices in a large university auditorium for example, we want more channels as this gives us more overall capacity. If I were to deploy a true 802.11ac network for a university in an auditorium that requires say for example 6 access points I will end up with channel reuse when I avoid DFS channels in 5GHz. The channel reuse will degrade the performance of those access points using the same channel. Now if I deploy the same 6 access points with 40MHz channels I no longer have to worry about channel reuse in that auditorium. Read More »
Tags: #ciscochampion, 802.11ac
#CiscoChampion Radio is a podcast series by
#CiscoChampion Radio is a podcast series by
Often times we get so busy with work we become robotic, and even worse – we forget to live. The funny thing is, by the time we realize it, rather than making some significant change, we just keep working to distract ourselves from the uncomfortable truth. As we strive to stay current with the evolution of technologies, certifications and the world around us, we quickly become overwhelmed, placing our wellbeing and sense of self at risk. We have a thousand things going on at work, two thousand things to catch up on, a hundred books to read, tests to take, projects to complete, deadlines to meet, and, oh yeah, an entirely separate life to live with family and loved ones, plus housework, hobbies and so on, all with a phone screen glued to our eyes, constantly checking email and social media. It’s quite an amazing feat to take on such a loaded life and remain happy.
