A Summary of Cisco VXLAN Control Planes: Multicast, Unicast, MP-BGP EVPN

With the adoption of overlay networks as the standard deployment for multi-tenant network, Layer2 over Layer3 protocols have been the favorite among network engineers. One of the Layer2 over Layer3 (or Layer2 over UDP) protocols adopted by the industry is VXLAN. Now, as with any other overlay network protocol, its scalability is tied into how well it can handle the Broadcast, Unknown unicast and Multicast (BUM). That is where the evolution of VXLAN control plane comes into play.

The standard does not define a “standard” control plane for VXLAN. There are several drafts describing the use of different control planes. The most commonly use VXLAN control plane is multicast. It is implemented and supported by multiple vendors and it is even natively supported in server OS like the Linux Kernel.

This post tries to summarize the three (3) control planes currently supported by some of the Cisco NX-OS/IOS-XR. My focus is more towards the Nexus 7k, Nexus 9k, Nexus 1k and CSR1000v.

Each control plane may have a series of caveats in their own, but those are not covered by this blog entry. Let’s start with some VXLAN definitions:

(1) VXLAN Tunnel Endpoint (VTEP): Map tenants’ end devices to VXLAN segments. Used to perform VXLAN encapsulation/de-encapsulation.
(2) Virtual Network Identifier (VNI): identify a VXLAN segment. It hast up to 224 IDs theoretically giving us 16,777,216 segments. (Valid VNI values are from 4096 to 16777215). Each segment can transport 802.1q-encapsulated packets, theoretically giving us 212 or 4096 VLANs over a single VNI.
(3) Network Virtualization Endpoint or Network Virtualization Edge (NVE): overlay interface configured in Cisco devices to define a VTEP

VXLAN with Multicast Control Plane
VXLAN1

Read More »
