Nexus Flexibility Eases Transitions

Cisco has a broad base of data center customers with a diverse set of requirements and we meet their needs with Nexus -- the most comprehensive switching portfolio in the industry.  This week, we are making announcements for both the Nexus 9000 series and the Nexus 3000 series that provide design and deployment flexibility for our commercial, enterprise, service provider, as well as cloud customers.  Key points of the announcement include:

  • ACI (Application Centric Infrastructure) is shipping this month;
  • Additional linecard and chassis options provide customer choice and flexibility;
  • 100G linecards for the Nexus 9500 will be available in Q4CY14 and will offer the highest density in the industry; and
  • New starter kits and bundles help customers ease transitions.

Nexus 9000 family

The Nexus 9000 Series

 ACI is shipping this month

 The Nexus 9000 series can operate in standard NX-OS mode or in ACI mode. In either case the Nexus 9000 portfolio delivers the value of the “5 P’s” of Power efficiency, Price, Port density, Performance, and Programmability. NX-OS mode provides customers with the value of the NX-OS operating system used by tens of thousands of customers in data centers around the world.  ACI mode adds to NX-OS capabilities by providing an application driven policy model, integration of hardware and software, and centralized visibility, among other things. ACI requires a controller and switch software.  Both are shipping this month. It is important to note that the pricing for this solution is simple and predictable.  There is a perpetual license for each leaf switch.  Other pricing approaches in the industry are monthly and are based on varying elements like number of VM’s.  Comparing the two approaches is somewhat like comparing a cell phone bill that is either flat rate or usage based.  Personally, I like the simplicity and predictability of flat rate.  See http://blogs.cisco.com/datacenter/aci-fcs/ for additional details on new ACI announcements and how they can take you beyond SDN.

Additional linecard and chassis options underscore flexibility

We’ll consider how flexibility is delivered for both modular and fixed platforms.  For modular switching, the Nexus 9500 modular chassis family offers different line card options that can be mixed in the same chassis and allow customers to “dial up” or “dial down” their design based upon the price, performance, feature set, and scale they want to achieve.  There are basically 3 different ‘flavors’, all of which are now shipping:

  1. The Nexus 9500 X9400 set of 1/10G and 40G line cards are based on merchant silicon and provide industry-leading price and performance compared to other merchant silicon switches. These provide a very cost effective solution ideal for traditional modular data center designs.
  2. The Nexus 9500 X9500 set of 1/10G and 40G line cards are sometimes referred to as “merchant plus” because they have custom Cisco ASICs, in addition to merchant silicon, and are ideal for customers that need performance together with additional buffering and VXLAN routing capabilities. The X9500 line cards can be used in future ACI designs as well.
  3. The Nexus 9500 X9600 set of 40G line cards provide performance without compromise even for small packet sizes.

The Nexus 9300 series offers ACI capabilities (ala the X9500 linecards in item 2 above) in a fixed form factor.  For customers interested in a merchant only fixed form factor, we offer the Nexus 3000 family.  This week, we announced the new Nexus 3164, which provides 64 ports of 40G and is a great solution for 40G access or space constrained aggregation.

100G linecards

We are also announcing 100G linecards that we believe will deliver industry leading port density of up to 128 ports of 100G in a single chassis.  100G for both the X9400 and X9600 series will be available for the Nexus 9500 in Q4CY14.  Cisco will offer an 8 port 100G X9400 line card and a 12 port 100G X9600 line card.

New starter kits and bundles ease transitions

There are numerous packages available to ease transitions -- from 1G to 10G, 10G to 40G, or from traditional networks to ACI.  There are 2 bundles I want to quickly call out.  The first provides a smooth transition for customers with older End of Row Catalyst 6500’s in their data centers.  It occupies the same rack space and uses the same cabling as they currently have, but provides 10X the performance.  The second is basically an ACI starter kit, providing the APIC, spine switches and leaf switches, even optical cables – everything required to set up and get started with an ACI pod.

In summary, Cisco is continuing its rapid pace of innovation and execution around ACI and data center switching overall.  Ultimately, this means customers gain choice, flexibility and true innovation to support their business needs.

Tags: , , , , , , , , , , , ,

Decoding UCS Invicta – Part 3

In part one of this series we covered the internals of HDDs, in part two we went over the internals of SSD, In part three we continue reviewing storage concepts to refresh or learn the right lingo.

Lets start by understanding “Redundant Array of Independent Disks” (RAID). There are RAID levels like RAID0 and RAID1 that are easily to understand and others like RAID5 and RAID6, which many sysadmins misunderstand.

Redundant Array of Independent Disks (RAID)

In the past RAID was also referred as a “Redundant Array of Inexpensive Disks”.  At the end of the day Read More »

Tags: ,

SDN and Beyond: Cisco ACI Starts Shipping to Data Centers Worldwide on July 31!

July 29, 2014 at 5:00 am PST

ACI goes beyond SDN to help customers deliver business outcomes and not just network device programmability.  That’s part of the reason over 175 customers signed up to trial the APIC during the hardware beta.  Now Cisco ACI will start shipping to Data Centers worldwide on July 31!

From when we first announced the Vision for an Application Centric Infrastructure at Cisco Live Orlando in 2013, it’s been extremely exciting to see customers and ecosystem partners support this new operational model for centrally configuring, automating and operating network and security infrastructure.

The application model for abstracting network infrastructure requirements and policies really does address the operational needs of the infrastructure and application teams.  That was by design, as Insieme’s engineering team worked with the leading cloud infrastructure customers of the world and our Cisco IT organization to incorporate their operational and application needs.  In fact, IDC published a powerful report to confirm the ACI related 3 year OpEx savings forecast at Cisco’s IT Elastic Infrastructure Services (CITEIS), one of the largest data center environments in the world.  Read the IDC Business Value Brief on Cisco ACI to learn more.

With the production APIC, customers can now begin running production applications on ACI.  For insights into why our customers are deploying ACI, we spoke with the leaders of two world-class IT companies that are aggressively rolling out ACI within their own corporate IT.

Symantec IT is an early adopter of ACI and Sean Doherty (VP of Alliances Offerings, Symantec) spoke recently with Shashi Kiran (Senior Director, Cisco) about automating their IT infrastructure with ACI.  About the Symantec IT environment,  Sean said, “Some applications have been through the Physical to Virtual cycle and others are placed on clouds. We are looking to move those into a more modern agile environment. The ACI is providing the infrastructure to build out that new environment…”.  Sean added that ACI helps in significantly accelerating the detection and remediation of security issues with business critical applications.  Check out this YouTube video interview for the full story.

Symantec Doherty NetApp KiddSymantec DohertySymantec Doherty

Representing another user adopting ACI, NetApp’s CTO Jay Kidd spoke recently about the ACI project in their global development lab.  He said this is a large scale deployment covering 2300 racks of equipment wired end-to-end with 40G capacity with Nexus 9000.  Talking about the lab, Jay stated, “One of the beauties of the (Nexus) 9K is the ability to gracefully transition and combine 10Gig and 40Gig together in the same infrastructure. Then with ACI, being able to build up these profiles for the applications or the test scenarios for those applications, store them, provision them dynamically. Anything we can do to make it easier for our developers to use this DevOps private cloud, we think will speed up the time to market and ACI is big part of that”.  The Lab can spin up thousands of Virtual Machines per hour with an aggregate capacity of running well in excess of a million VMs at a given time.  You can  listen to Jay’s eloquent explanation on YouTube here.

NetApp Kidd

Our Cisco sales teams have a great way to help Cisco customers to begin their own ACI deployments with the new ACI Starter Bundles.   An ACI Starter Bundle (Fig 1) has everything you need to create an ACI POD including a resilient cluster of three APICs, two fixed or modular spine switches, eight 40G optics, and two or four leaf switches depending on which of the four bundles are selected.

Figure 1  ACI Starter Bundles include an APIC Cluster with 3 APICs and 8 40G AOC optics

  • #1 Two Fixed Spine Switches, Four Leaf Switches with 192 Ports
  • #2 Two Fixed Spine Switches, Four Leaf Switches with 384 Ports
  • #3 Two Modular Spine Switches, Two Leaf Switches with 96 Ports
  • #4 Two Modular Spine Switches, Two Leaf Switches with 192 Ports

Cisco customers can use ACI Starter Bundles 1 or 2 as policy appliance for flexible/ granular network virtualization and secure isolation in conjunction with their existing base of Nexus 2000 to Nexus 7000 (Fig. 2)

Figure 2 ACI Starter Bundles #1 or #2

Slide1

ACI Starter Bundles #1 or #2 can also be used to scale out a UCS converged infrastructure solution such NetApp FlexPod and VCE VBlock. (Fig. 3)

Figure 3 Scale out UCS Converged Infrastructure Solutions

Slide1

ACI Starter Bundles #3 or #4 can be used as a starting point to scale out private clouds with secure multi-tenancy since they are based upon the more expandable modular chassis. (Fig. 4)

Figure 4

Slide1

When used in conjunction with the just released Application Virtual Switch, AVS, the APIC provides centralized policy based control and automation for any application composed of any number of server tiers containing any number of virtual or physical servers.  These ACI starter bundles enable customers to begin ACI deployments for testing or production operations.  The simple fixed price licensing for a set of leaf ports, 48 or 96, means there is no penalty for running lots of VMs per server vs. bare metal servers. (Fig 5) Customers can predict the cost of running their software defined network infrastructure.

Figure 5 No per VM Tax with ACI licensing

Servers

Contact your Cisco account manager to learn how the cost of an ACI POD is less than the cost of  those dedicated x86 hardware gateways required with leading pure software overlay approaches.  ACI delivers more scale, security, and performance at a fixed predictable cost with documented TCO benefits.

Many of our ecosystem partners announced at Cisco Live that they would be shipping their ACI Device Packages when Cisco’s APIC enters FCS.  The following joint solutions have passed rigorous interoperability testing conducted jointly by the vendor’s and Cisco’s engineering teams in our own ACI testing lab.   These partners demonstrate ACI’s open ecosystem for service integration, investment protection for existing ADC networks, and the benefits of a centralized control point for L2-L3 network and L4-L7 service policy coordination and automation.

  • Cisco ASA security and Cisco ACI solution:   Customers can now deploy Cisco ACI with Cisco ASA and its ACI Device Package to provide automated, policy-based security provisioning, management, and security policy updates, for firewall, intrusion prevention,  and more.
  • Citrix NetScaler and Cisco ACI joint solution:  Customers can use the APIC to coordinate the Citrix NetScaler’s ADC unique application insights for optimized service delivery with ACI’s network automation and obtain end-to-end telemetry and visibility for service-aware applications and tenants.
  • Embrane and Cisco ACI joint solution:  With the APIC and Embrane’s ACI Device Package, ESM automates the deployment and lifecycle management of Embrane’s network virtual services as well as those from Cisco ASA, Sourcefire, and Citrix.
  • F5 Synthesis and Cisco ACI joint solution: Customers can accelerate application deployment by automating insertion of SSL offload and L4-L7 SLB services using F5’s ACI Device Package and the Cisco APIC.

We are publishing interviews with the analysts, the leading practitioners that are hands on with ACI in August in an exciting ACI special edition of Unleashing IT.   I’ll share the link for you here in a few weeks.

Today, we had some great news to share on Data Center and Cloud  Networks.  The Cisco ACI solution portfolio was orderable on July 1 and starts shipping July 31.  This includes the four ACI starter bundles detailed above.  For details on today’s exciting new Nexus switches nnouncement,  please visit this blog -- Nexus Flexibility Eases Transitions.

Links for more information

IDC: Optimizing the Datacenter Network for Improved Scalability, Orchestration, and Automation

An Application-Centric Infrastructure Will Enable Business Agility

ESG: Accelerating Transformation with an Application-centric Approach

Cisco Application Centric Infrastructure and Cisco Nexus Switching: Delivering Investment Protection



Tags: , , , , ,

The Future of Cloud, Part 5: The Value of Integration to Cloud Services

(This is part 5 of a 7-part series sharing insights from Cisco partners about the Future of Cloud.)

“A lot of things go into building out a cloud practice that most people don’t realize until they get into it.  Because we have been a systems integrator, we know the on-premises environment very well.  That gives us an advantage over some cloud providers who may be more like service providers.  They just don’t understand the integration piece. ”

This was just one of the insights Chris Ludwig, SVP GTM Cloud and Hosted Solutions from NWN Corporation, shared with me at Cisco Live!  NWN is a provider of Cisco Powered cloud and managed services.  Their first service offering, hosted collaboration, has created substantial pull-through for the later IaaS services they have added.

Integration is an important part of a successful migration to cloud, according to Ludwig. Cisco has a whole ecosystem that has built applications to integrate with on-premises equipment.  When moving to cloud, all of these integrations still have to work.  “That was something we did a lot of research on, to make sure that all of the third party companies that we work with on-premises are going to work in the cloud.”

For NWN, the value of the Cisco partner ecosystem cannot be underestimated.  Regarding which partners to work with, Ludwig said, “We certainly look to Cisco for guidance.  We don’t want to pick a partner and then find out something doesn’t work right.

“It’s very helpful knowing that if they’re part of the ecosystem, we know that they are going to be a good partner.  That they are going to be around.  That they know how to work with the Cisco team and technology.”

You can also learn more about how providers are addressing the need for enterprise class services in the latest edition of Unleashing IT.

Tags: , , , ,

Power of Open Choice in Hypervisor Virtual Switching

July 28, 2014 at 5:00 am PST

Customers gain great value from server virtualization in the form of virtual machines (VM) and more recently Linux Containers /Dockers in data centers, clouds and branches.  By some estimates, more than 60 % of the workloads are virtualized although less than 16% of the physical servers (IDC) are virtualized (running a hypervisor).  From a networking perspective, the hypervisor virtual switch on these virtualized servers plays a critical component in all current and future data center, cloud, and branch designs and solutions

As we count down to the annual VMworld conference and reflect on the introduction of the Cisco Nexus 1000V in vSphere 4.0 six years ago, we can feel proud of what we have achieved. We have to congratulate VMware for their partnership and success in opening vSphere networking to third party vendors. It was beneficial for our joint customers, and for both companies. VMware and Cisco could be considered visionaries in this sense. Recognizing this success, the industry has followed.

Similarly we praise Microsoft as well, for having also provided an open environment for third-party virtual switches within Hyper-V, which has continued gaining market share recently.  Cisco and Microsoft (along with other industry players) are leading the industry with the latest collaboration on submitting the OpFlex control protocol to the IETF. Microsoft’s intention to enable OpFlex support in their native Hyper-V virtual switch enables standards-based interaction with the virtual switches.  Another win for customers and the industry.

In KVM and Xen environments, many organizations have looked at Open vSwitch (OVS) as an open source alternative. There is an interest in having richer networking than the standard Linux Bridge provides, or using OVS as a component for implementing SDN-based solutions like network virtualization. We think that there is an appetite for OVS on other hypervisors as well.  Cisco is also committed to contributing and improving these open source efforts.  We are active contributors in the Open Virtual Switch project and diligently working to open source our OpFlex control protocol implementation for OVS in the OpenDaylight consortium.

To recap on the thoughts from above, Table 1 provides a quick glance at the options for virtual networking from multiple vendors as of today:

Table 1:  Hypervisors and Choices in Virtual Switches

Hypervisor

Native vSwitch

3-party or OpenSource  vSwitch

vSphere

•Standard vSwitch
•Distributed Virtual Switch
•Cisco Application Virtual Switch
•IBM DVS 5000V
•HP Virtual Switch 5900V

Hyper-V

Native Hyper-v Switching
•NEC
•Broadcom

KVM

Linux Bridge(some distributions include OVS natively)
•OVS

XEN

OVS -- open source project with multiple contributions from different vendors and individuals
•OVS



As an IT Professional, whether you are running workloads on Red Hat KVM, Microsoft Hyper-V or VMware vSphere, it is difficult to imagine not having a choice of virtual networking. For many customers, this choice still means using the hypervisor’s native vSwitch.  For others, it is about having an open source alternative, like OVS. And in many other cases, having the option of selecting an Enterprise-grade virtual switch has been key to increasing deployments of virtualization, since it enables consistent policies and network operations between virtual machines and bare metal workloads.

As can be seen in the table above, Cisco Nexus 1000V continues to be the industry’s only multi-hypervisor virtual switching solution that delivers enterprise class functionality and features across vSphere, Hyper-V and KVM. Currently, over 10,000 customers have selected this option with Cisco Nexus 1000V in either vSphere, Hyper-V, or KVM (or a combination of them).

Cisco is fully committed to the Nexus 1000V for vSphere, Hyper-V and KVM and also the Application Virtual Switch (AVS) for Application Centric Infrastructure (ACI), in addition to our open source contributions to OVS.  Cisco has a large R&D investment in virtual switching, with a lot of talented engineers dedicated to this area, inclusive of those working on open-source contributions.

Nexus 1000V 3.0 release for vSphere is slated for August 2014 (general availability). This release addresses scale requirements of our increasing customer base, as well as an easy installation tool in the form of Cisco Virtual Switch Update Manager.   The Cisco AVS for vSphere will bring the ACI policy framework to virtual servers.  With ACI, customers will for the first time benefit from a true end-to-end virtual + physical infrastructure being managed holistically to provide visibility and optimal performance for heterogeneous hypervisors and workloads (virtual or physical).  These innovations and choices are enabled by the availability of open choices in virtual switching within hypervisors.

As we look forward to VMworld next month, we are excited to continue the collaborative work with platform vendors VMware, Microsoft, Red Hat, Canonical, and the open source community to maintain and continue development of openness and choice for our customers.  We are fully committed to this vision at Cisco.

Acknowledgement:  Juan Lage (@juanlage) contributed to this blog.
