Cisco will Leverage OPNFV Efforts in Evolved Services Platform (ESP) Development
Most people following industry trends are aware of the ETSI Network Functions Virtualization (NFV) Industry Specification Group, which was formed in 2012 and kicked off its first set of specifications in October 2013. These documents are commonly used references in the growing movement to utilize NFV for carrier-grade network services.
Great progress has already been made, and Cisco has delivered many innovative NFV solutions via our Evolved Services Platform. To take it to the next level, and realize the full potential of NFV, customers will now start flexibly combining components from different vendors to enjoy the benefits of open source efforts.
Hence the announcement on Tuesday of Open Platform for Network Functions Virtualization (OPNFV), a new open source project focused on accelerating NFV’s evolution through an integrated, open platform. Cisco is a platinum-level founding member of the project, which will focus initially on the NFV infrastructure (NFVI) and infrastructure management (VIM) of the ETSI NFV Reference Architecture.
Source: Publications and Collateral page at opnfv.org.
OPNFV expects to Read More »
Tags: cisco esp, cloud dvr, evolved services platform, meraki, network functions virtualization, NFV, Service Provider, virtualization
This is the final part on the High Performance Data Center Design. We will look at how high performance, high availability and flexibility allows customers to scale up or scale out over time without any disruption to the existing infrastructure. MDS 9710 capabilities are field proved with the wide adoption and steep ramp within first year of the introduction. Some of the customer use cases regarding MDS 9710 are detailed here. Furthermore Cisco has not only established itself as a strong player in the SAN space with so many industry’s first innovations like VSAN, IVR, FCoE, Unified Ports that we introduced in last 12 years, but also has the leading market share in SAN.
Before we look at some architecture examples lets start with basic tenants any director class switch should support when it coms to scalability and supporting future customer needs
Design should be flexible to Scale Up (increase performance) or Scale Out (add more port)
The process should not be disruptive to the current installation for cabling, performance impact or downtime
The design principals like oversubscription ratio, latency, throughput predictability (as an example from host edge to core) shouldn’t be compromised at port level and fabric level
Lets take a scale out example, where customer wants to increase 16G ports down the road. For this example I have used a core edge design with 4 Edge MDS 9710 and 2 Core MDS 9710. There are 768 hosts at 8Gbps and 640 hosts running at 16Gbps connected to 4 edge MDS 9710 with total of 16 Tbps connectivity. With 8:1 oversubscription ratio from edge to core design requires 2 Tbps edge to core connectivity. The 2 core systems are connected to edge and targets using 128 target ports running at 16Gbps in each direction. The picture below shows the connectivity.
Down the road data center requires 188 more ports running at 16G. These 188 ports are added to the new edge director (or open slots in the existing directors) which is then connected to the core switches with 24 additional edge to core connections. This is repeated with 24 additional 16G targets ports. The fact that this scale up is not disruptive to existing infrastructure is extremely important. In any of the scale out or scale up cases there is minimal impact, if any, on existing chassis layout, data path, cabling, throughput, latency. As an example if customer doesn’t want to string additional cables between the core and edge directors then they can upgrade to higher speed cards (32G FC or 40G FCoE with BiDi ) and get double the bandwidth on the on the existing cable plant.
Lets look at another example where customer wants to scale up (i.e. increase the performance of the connections). Lets use a edge core edge design for this example. There are 6144 hosts running at 8Gbps distributed over 10 edge MDS 9710s resulting in a total of 49 Tbps edge bandwidth. Lets assume that this data center is using a oversubscription ratio of 16:1 from edge into the core. To satisfy that requirement administrator designed DC with 2 core switches 192 ports each running at 3Tbps. Lets assume at initial design customer connected 768 Storage Ports running at 8G.
Few years down the road customer may wants to add additional 6,144 8G ports and keep the same oversubscription ratios. This has to be implemented in non disruptive manner, without any performance degradation on the existing infrastructure (either in throughput or in latency) and without any constraints regarding protocol, optics and connectivity. In this scenario the host edge connectivity doubles and the edge to core bandwidth increases to 98G. Data Center admin have multiple options for addressing the increase core bandwidth to 6 Tbps. Data Center admin can choose to add more 16G ports (192 more ports to be precise) or preserve the cabling and use 32G connectivity for host edge to core and core to target edge connectivity on the same chassis. Data Center admin can as easily use the 40G FCoE at that time to meet the bandwidth needs in the core of the network without any forklift.
Or on the other hand customer may wants to upgrade to 16G connectivity on hosts and follow the same oversubscription ratios. . For 16G connectivity the host edge bandwidth increases to 98G and data center administrator has the same flexibility regarding protocol, cabling and speeds.
For either option the disruption is minimal. In real life there will be mix of requirements on the same fabric some scale out and some scale up. In those circumstances data center admins have the same flexibility and options. With chassis life of more than a decade it allows customers to upgrade to higher speeds when they need to without disruption and with maximum flexibility. The figure below shows how easily customers can Scale UP or Scale Out.
As these examples show Cisco MDS solution provides ability for customers to Scale Up or Scale out in flexible, non disruptive way.
“Good design doesn’t date. Bad design does.”
Tags: 16 Gigabit, 16Gb, 16Gb Fibre Channel, 9710, architecture, availability, best practices, Cisco, cloud, Cloud Computing, Consolidation, convergence, data center, Data Mobility Manager, DCNM, design, Director, dmm, FCIP, FCoE, Fibre Channel, Fibre Channel over Ethernet, IO accelerator, it-as-a-service, MDS, MDS design, nexus, NX-OS, reliability, SAN, Storage, storage area networks, switch, switching, Unified Data Center, Unified Fabric, virtualization
There is a video available on YouTube describing a collaborative project with Cox Communications on virtualized residential services. Dave Ward, Senior VP and CTO at Cisco Systems, is joined by Jeff Finklestein, Executive Director of Architecture at Cox Communications, and Alon Bernstein, Distinguished Engineer at Cisco. They discuss, in the context of Cisco’s Evolved Services Platform (ESP), how to rapidly implement a new service idea that Jeff and Dave cooked up: self-service virtual residential services.
In the proposed solution, a Cox customer logs in to a screen such as the following, and sees a virtual representation of services they can enable themselves from their home.
Jeff identified Read More »
Tags: cisco esp, cox communications, evolved services platform, network functions virtualization, network services orchestrator, NFV, virtualization
In this week’s episode of Engineers Unplugged, Roving Reporter Lauren Malhoit (@malhoit) talks to Adam Eckerle (@eck79) about #UCSGrandSlam and UCS as a platform. Great view of the tech from the admin perspective: “UCS is built from the ground up with virtualization in mind.” Great practical episode for anyone exploring UCS!
Much like UCS, the Unicorn Challenge is a platform for creativity.
**Want to be Internet Famous? Join us for our next shoot: VMworld Barcelona. Tweet me @CommsNinja!**
This is Engineers Unplugged, where technologists talk to each other the way they know best, with a whiteboard. The rules are simple:
- Episodes will publish weekly (or as close to it as we can manage)
- Subscribe to the podcast here: engineersunplugged.com
- Follow the #engineersunplugged conversation on Twitter
- Submit ideas for episodes or volunteer to appear by Tweeting to @CommsNinja
- Practice drawing unicorns
Join the behind the scenes by liking Engineers Unplugged on Facebook.
Tags: ACI, UCS, UCSGrandSlam, virtualization
Data Centers are becoming increasingly smart, intelligent and elastic. With the advancement in cloud and virtualization technologies, customers demand dynamic workload management, efficient and optimal use of their resources. In addition the configuration and administration of Data Center solutions is complex and is going to become increasingly so.
With these requirements and architectures in mind we have a industry first solution called Remote Integrated Service Engine (RISE). RISE is a technology that simplifies provisioning, out of box management of service appliances like load balancers, firewalls, network analysis modules. It makes data center and campus networks dynamic, flexible, easy to configure and maintain.
RISE can dynamically provision network resources for any type of service appliance (physical and virtual form factors). External appliances can now operate as integrated service modules with Nexus Series of switches without burning a slot in a switch . This technology provides robust application delivery capabilities that accelerate the application performance manifold.
RISE is supported on all Nexus Series switches with services like Citrix NetScaler MPX, VPX, SDX and Cisco Prime NAM with many more in the pipeline.
Advantages & Features
- Simplified Out-of-Box experience : reduces the administrator’s manual configuration steps from 30 to 8 steps !!
- Supported on Citrix NetScaler MPX, SDX, VPX, and Nexus 1KV with VPX
- Supported on Cisco Prime Network Analyzer Module
- Automatic Policy Based Routing – Eliminates need for SNAT or Manual PBR
- Direct and Indirect Attach mode integration
- Show module for RISE
- Attach module for RISE
- Auto Attach – Zero touch configuration of RISE
- Health Monitoring of appliance
- Appliance HA and VPC supported
- Nexus 5K/6K support (EFT available)
- IPV6 support (EFT available)
- DCNM support
- Order of magnitude OPEX savings: reduction in configuration, and ease of deployment
- Order of magnitude CAPEX savings: Wiring, Power Rackspace and Cost savings
For more information, schedule an EFT or POC Contact us at firstname.lastname@example.org
RISE press release on Wall Street Journal : http://online.wsj.com/article/PR-CO-20140408-905573.html
RISE At A Glance white paper: http://www.cisco.com/c/dam/en/us/products/collateral/switches/nexus-7000-series-switches/at-a-glance-c45-731306.pdf
RISE Video at Interop: https://www.youtube.com/watch?v=1HQkew4EE2g
Cisco RISE page: www.cisco.com/go/rise
Gartner blog on RISE: “Cisco and Citrix RISE to the Occasion”: http://blogs.gartner.com/andrew-lerner/2014/03/31/cisco-and-citrix-rise-to-the-adc-occasion/
