Don’t be Bewitched by the Switch – What You Need to Know when You Evaluate Solutions

It’s undeniable that the biggest convergence happening in the access layer is Wired/Wireless. Today, we’re no longer forced to treat wired and wireless any differently when it comes to network visibility and management. However, the unification of Wired/Wireless doesn’t come without its own challenges and complexity.

As we’ve seen with the latest switching announcement at Interop 2015, there is a lot of noise in the marketplace and customers and partners increasingly need to cut through this to achieve their IT goals and meet today’s increasing demands on the network and the demands of tomorrow.

Earlier this week, HP made false claims about our Catalyst 4500E switch. To help you out, here is what you need to know about Cisco switching and, specifically, our Catalyst 4500E switch:

  • As the world becomes increasingly more digital, there is an elevated need for a flexible and scalable network to address rapid shifts in technology use and its associated traffic. We’ve seen tremendous demand for our modular switches that supply the best flexibility for this change. In fact, Cisco has the industry’s most widely deployed modular access switches with a modular PoE port share that just reached an all time high of 81.5 percent.
  • To tackle the biggest convergence in the access layer, Catalyst 4500E supports built-in wireless controller capabilities and delivers common intelligent services across wired and wireless for security and policy, application visibility and control, network resiliency, smart operations, and more.
  • Cisco’s Catalyst Multigigabit (mGig) technology available across the access portfolio including the Catalyst 4500E can prepare customers’ access switches for the next wave in wireless, 802.11ac wave 2 by delivering speeds beyond 1 Gigabit on existing Category 5e cables. This technology also supports PoE, PoE+, and Cisco Universal PoE (UPOE) so you don’t need to install new electrical circuits to power your access points.
  • Cisco’s modular access switch portfolio offers backward compatibility with up to three generation of line-cards providing unmatched investment protection – 2x in terms of number of years over other vendors.
  • A key operational consideration for IT is to maximize uptime and provide seamless code upgrades. In Service software upgrades (ISSU) have been available on Cisco’s 4500E portfolio for almost a decade
  • The Catalyst 4500E has unmatched scale to meet the needs of a customer’s network and future proof for an influx of new devices – 25X route entries, 16X multicast entries & 42X Security/QoS entries when compared to other vendors.
  • As IoT trends upward, more “things” connect to the access network and it is key that the network is able to scale to meet these needs – Cisco offers 33 percent more scale in terms of POE+ ports and 50 percent more POE+ scale for redundant power deployments to connect more users, devices and things. Additionally, Cisco supports UPOE, which future-proofs our customers for upcoming applications requiring more than 30W/port.
  • Security is a top of mind for our customers and Cisco offers a complete end-to-end solution with support for MacSec, Cisco TrustSec, Identity Services Engine and Flexible Netflow, providing the best in class network encryption, segmentation and networking sensing solutions.
  • The Catalyst 4500E is designed for supporting rich media services with its superior multicast scale and design. Cisco Catalyst 4500 is designed to support hardware accelerated multicast with deep buffers. The Cisco Catalyst 4500E accommodates up to nine times larger data bursts, delivered to otherwise loaded output ports, without loss.
  • Cisco Catalyst 4500E supports a multitude of capabilities that support IT simplicity and smart operations. Examples: Simplified provisioning with Plug and Play, Simplified configuration of switches & interfaces with AutoConfiguration and Interface templates and faster troubleshooting with embedded wireshark, a world-class protocol analyzer.

Read More »

Tags: , , , , , , ,

See Cisco’s Proof Of Concept, IP-based Video Switch at NAB



Peter ChaveGuest Blog by – Peter Chave, Technical Engineering Leader, Cisco Video Software and Solutions

For as long as there’s been cause for broadcast video engineers to get together to talk shop, there’s been that big blob in the middle of the topological diagram — the frame-accurate crosspoint router, based on the coaxial workhorse that is the SDI (Serial Digital Interface.)

And at this week’s National Association of Broadcasters, in Las Vegas, broadcast video technologists will again assess the fate of SDI-based technologies, along the prism that is the inevitable and worldwide shift to their Internet Protocol (IP)-based successors.

The quest for an IP-based video switch — built from the off-the-shelf hardware that rides the cost curves happening in data centers Read More »

Tags: , , , , , , , , , , , ,

NAB 2015: Cisco Welcomes New Global Independent Software Vendors to Software Solutions Program

Paul BoscoGuest Blog by, Paul Bosco, vice president, market development, Cisco Service Provider business

 At NAB this week, Cisco is showcasing to media and entertainment companies its certification of independent software vendors (ISV) focused on media-centric applications.

The solutions available to customers involve a host of software applications paired with the Cisco Unified Computing System™ (UCS), and/or multiple Cisco Nexus 7000 and 3000 Series switches. Select demos of these solutions in action will be showcased at Read More »

Tags: , , , , , , , , ,

Why Upgrade to MDS 9700

MDS 9500 family has supported customers for more than a decade helping them  through FC speed transitions from 1G, 2G, 4G, 8G and 8G advanced without forklift upgrades. But as we look in the future the MDS 9700 makes more sense for a lot of data center designs.  Top four reasons for customers to upgrade are

  1. End of Support Milestones
  2. Storage Consolidation
  3. Improved Capabilities
  4. Foundation for Future Growth

So lets look at each in some detail.

  1. End of Support Milestones

MDS 4G parts are going End of Support on Feb 28th 2015. Impacted part numbers are DS-X9112, DS-X9124, DS-X9148. You can use the MDS 9500 Advance 8G Cards or MDS 9700 based design. Few advantages MDS 9700 offers over any other existing options are

a. Investment Protection – For any new Data Center design based on MDS 9700 will have much longer life than MDS 9500 product family. This will avoid EOL concerns or upgrades in near future. Thus any MDS 9700 based design will provide strong investment protection and will also ensure that the architecture is relevant for evolving data center needs for more than a decade.

b. EOL Planning – With MDS 9700 based design you control when you need to add any additional blades but with MDS 9500, you will have to either fill up the chassis within 6 months (End of life announcement to End of Sales) or leave the slots empty forever after End of Sale date.

c. Simplify Design – MDS 9700 will allow single skew, S/W version, consistent design across the whole fabric which will simplify the management. MDS 9700 massive performance allows for consolidation and thus reducing footprint and management burden.

d. Rich Feature Set – Finally as we will see later MDS provides host of features and capabilities above and beyond MDS 9500 and that enhancement list will continue to grow.

 Tech Refresh Example v1

  1. Storage Consolidation

MDS 9700 provides unprecedented consolidation compared to the existing solutions in the industry. As an example with MDS 9710 customers can use the 16G Line Rate ports to support massively virtualized workload and consolidate the server install base. Secondly with 9148S as Top of Rack switch and MDS 9700 at Core, you can design massively scalable networks supporting consistent latency and 16G throughput independent of the number of links and traffic profile and will allow customers to Scale Up or Scale Out much more easily than legacy based designs or any other architecture in the industry.

Moreover as shown in figure above for customers with MDS 9500 based designs MDS 9710 offers higher number of line rate ports in smaller footprint and much more economical way to design SANs. It also enables consolidation with higher performance as well as much higher availability.

Small SANs to Large SAN Design v1



  1. Improved Capabilities

MDS 9700 design provides more enhanced capabilities above and beyond MDS 9500 and many more capabilities will be added in future. Some examples that are top of mind are detailed below

Availability: MDS 9700 based design improves the reliability due to enhancements on many fronts as well as simplifying the overall architecture and management.

    • MDS 9710 introduced host of features to improve reliability like industry’s first N+1 Fabric redundancy, smaller failure domains and hardware based slow drain detection and recovery.
    • Its well understood that reliability of any network comes from proper design, regular maintenance and support. It is imperative that Data Center is on the recommended releases and supported hardware. As an example data center outage where there are unsupported hardware or software version failure are exponentially more catastrophic as the time to fix those issues means new procurement and live insertion with no change management window. Cost of an outage in an Data Center is extremely high so it is important to keep the fabric upgraded and on the latest release with all supported components. Thus for new designs it makes sense that it is based on the latest MDS 9700 directors, as an example, rather than MDS 9513 Gen-2 line cards because they will fall of the support on Feb 28, 2015. Also a lot of times having different versions of the hardware and different software versions add complexity to the maintenance and upkeep and thus has a direct impact on the availability of the network as well as operational complexity.

Throughput:

With massive amounts of virtualization the user impact is much higher for any downtime or even performance degradation. Similarly with the data center consolidation and higher speeds available in the edge to core connectivity more and more host edge ports are connected through the same core switches and thus higher number of apps are dependent on consistent end to end performance to provide reliable user experience. MDS 9700 provides industries highest performance with 24Tbps switching capability. The Director class switch is based on Crossbar architecture with Central Arbitration and Virtual Output Queuing which ensures consistent line rate 16G throughput independent of the traffic profile with all 384 ports operating at 16G speeds and without using crutches like local switching (muck akin to emulating independent fixed fabric switches within a director), oversubscription (can cause intermittent performance issues) or bandwidth allocation.

Latency:

MDS Directors are store and forward switches this is needed as it makes sure that corrupted frames are not traversing everywhere in the network and end devices don’t waste precious CPU cycles dealing with corrupted traffic. This additional latency hit is OK as it protects end devices and preserves integrity of the whole fabric. Since all the ports are line rate and customers don’t have to use local switching. This again adds a small latency but results in flexible scalable design which is resilient and doesn’t breakdown in future. These 2 basic design requirements result in a latency number that is slightly higher but results in scalable design and guarantees predictable performance in any traffic profile and provides much higher fabric resiliency .

Consistent Latency: For MDS directors latency is same for the 16G flow to when there are 384 16G flows going through the system. Crossbar based switch design, Central arbitration and Virtual Output Queuing guarantees that. Having a variable latency which goes from few us to a high number is extremely dangerous. So first thing you need to make sure is that director could provide consistent and predictable latency.

End to End latency: Performance of any application or solution is dependent on end to end latency. Just focusing on SAN fabric alone is myopic as major portion of the latency is contributed by end devices. As an example spinning targets latency is of the order of ms. In this design few us is orders of magnitude less and hence not even observable. With SSD the latency is of the order of 100 to 200 us. Assuming 150 us the contribution of SAN fabric for edge core is still less than 10%. Majority (90%) of the latency is end devices and saving couple of us in SAN Fabric will hardly impact the overall application performance but the architectural advantage of CRC based error drops and scalable fabric design will make provided reliable operations and scalable design.

Scalability:

For larger Enterprises scalability has been a challenge due to massive amount of host virtualization. As more and more VMs are logging into the fabric the requirement from the fabric to support higher flogins, Zones. Domains is increasing. MDS 9700 has industries highest scalability numbers as its powered by supervisor that has 4 times the memory and compute capability of the predecessor. This translates to support for higher scalability and at the same time provides room for future growth.

MDS 9700 Capabilities v2

Foundation for Future Growth:

MDS 9700 provides a strong foundation to meet the performance and scalability needs for the Data Center requirements but the massive switching capability and compute and memory will cover your needs for more than a decade.

    • It will allow you to go to 32G FC speeds without forklift upgrade or changing Fabric Cards (rather you will need 3 more of the same Fabric card to get line rate throughput through all the 384 ports on MDS 9710 (and 192 on MDS 9706).
    • MDS 9700 allow customers to deploy 10G FCoE solution today and upgrade without forklift upgrade again to 40G FCoE.
    • MDS 9700 is again unique such that customers can mix and match FC and FCoE line cards any way they want without any limitations or constraints.

Most importantly customers don’t have to make FC vs FCoE decision. Whether you want to continue with FC and have plans for 32G FC or beyond or if you are looking to converge two networks into single network tomorrow or few years down the road MDS 9700 will provide consistent capabilities in both architectures.

Foundation for Future Growth v1

In summary SAN Directors are critical element of any Data Center. Going back in time the basic reason for having a separate SAN was to provide unprecedented performance, reliability and high availability. Data Center design architecture has to keep up with the requirements of new generation of application, virtualization of even the highest performance apps like databases, new design requirements introduced by solutions like VDI, ever increasing Solid State drive usage, and device proliferation. At the same time when networks are getting increasingly complex the basic necessity is to simplify the configuration, provisioning, resource management and upkeep. These are exact design paradigms that MDS 9700 is designed to solve more elegantly than any existing solution.

Although I am biased in saying that but it seems that you have voted us with your acceptance. Please see some more details here.





Live as if you were to die tomorrow. Learn as if you were to live forever.
Mahatma Gandhi





Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

MDS 9700 Scale Out and Scale Up

This is the final part on the High Performance Data Center Design. We will look at how high performance, high availability and flexibility allows customers to scale up or scale out over time without any disruption to the existing infrastructure.  MDS 9710 capabilities are field proved with the wide adoption and steep ramp within first year of the introduction. Some of the customer use cases regarding MDS 9710 are detailed here. Furthermore Cisco has not only established itself as a strong player in the SAN space with so many industry’s first innovations like VSAN, IVR, FCoE, Unified Ports that we introduced in last 12 years, but also has the leading market share in SAN.

Before we look at some architecture examples lets start with basic tenants any director class switch should support when it coms to scalability and supporting future customer needs

  • Design should be flexible to Scale Up (increase performance) or Scale Out (add more port)
  • The process should not be disruptive to the current installation for cabling, performance impact or downtime
  • The design principals like oversubscription ratio, latency, throughput predictability (as an example from host edge to core) shouldn’t be compromised at port level and fabric level

Lets take a scale out example, where customer wants to increase 16G ports down the road. For this example I have used a core edge design with 4 Edge MDS 9710 and 2 Core MDS 9710. There are 768 hosts at 8Gbps and 640 hosts running at 16Gbps connected to 4 edge MDS 9710 with total of 16 Tbps connectivity. With 8:1 oversubscription ratio from edge to core design requires 2 Tbps edge to core connectivity. The 2 core systems are connected to edge and targets using 128 target ports running at 16Gbps in each direction. The picture below shows the connectivity.

Edge Core Design Day 1

Down the road data center requires 188 more ports running at 16G. These 188 ports are added to the new edge director (or open slots in the existing directors) which is then connected to the core switches with 24 additional edge to core connections. This is repeated with 24 additional 16G targets ports. The fact that this scale up is not disruptive to existing infrastructure is extremely important. In any of the scale out or scale up cases there is minimal impact, if any, on existing chassis layout, data path, cabling, throughput, latency. As an example if customer doesn’t want to string additional cables between the core and edge directors then they can upgrade to higher speed cards (32G FC or 40G FCoE with BiDi ) and get double the bandwidth on the on the existing cable plant.

Edge Core Design Scale UP

Lets look at another example where customer wants to scale up (i.e. increase the performance of the connections). Lets use a edge core edge design for this example. There are 6144 hosts running at 8Gbps distributed over 10 edge MDS 9710s resulting in a total of 49 Tbps edge bandwidth. Lets assume that this data center is using a oversubscription ratio of 16:1 from edge into the core. To satisfy that requirement administrator designed DC with 2 core switches 192 ports each running at 3Tbps. Lets assume at initial design customer connected 768 Storage Ports running at 8G.

Edge Core Design Day1



Few years down the road customer may wants to add additional 6,144 8G ports  and keep the same oversubscription ratios. This has to be implemented in non disruptive manner, without any performance degradation on the existing infrastructure (either in throughput or in latency) and without any constraints regarding protocol, optics and connectivity. In this scenario the host edge connectivity doubles and the edge to core bandwidth increases to 98G. Data Center admin have multiple options for addressing the increase core bandwidth to 6 Tbps.  Data Center admin can choose to add more 16G ports (192 more ports to be precise) or preserve the cabling and use 32G connectivity for host edge to core and core to target edge connectivity on the same chassis. Data Center admin can as easily use the 40G FCoE at that time to meet the bandwidth needs in the core of the network without any forklift. Edge Core Edge Design Scale Out

Or on the other hand customer may wants to upgrade to 16G connectivity on hosts and follow the same oversubscription ratios. . For 16G connectivity the host edge bandwidth increases to 98G and data center administrator has the same flexibility regarding protocol, cabling and speeds.

Edge Core Edge Example 1 ScaleUP

For either option the disruption is minimal. In real life there will be mix of requirements on the same fabric some scale out and some scale up. In those circumstances data center admins have the same flexibility and options. With chassis life of more than a decade it allows customers to upgrade to higher speeds when they need to without disruption and with maximum flexibility. The figure below shows how easily customers can Scale UP or Scale Out.



Edge Core Edge Design Scale Out Scale Up



As these examples show Cisco MDS solution provides ability for customers to Scale Up or Scale out in flexible, non disruptive way.

“Good design doesn’t date. Bad design does.”
Paul Rand
