Cisco at OpenStack Summit, Paris

Cisco is again a Premiere Sponsor of the OpenStack Summit, November 3-7 at Le Palais des Congrès in Paris.  Here’s a summary of Cisco sponsored activities for your schedule.

Paris view

Premier Breakout Session:  “A World of Many (OpenStack) Clouds”
Wed. 05 Nov; 13:50 – 14:30
Cisco VP and Cloud CTO, Lew Tucker, will talk about how Cisco is working with leading service providers and enterprise customers to enable a world of interconnected clouds.  Find out how Cisco is delivering greater automation, programmability, and openness for IT infrastructure, to support the next generation of virtualization and cloud.

Cisco Expo Booth, Location #C3
Stop by and pick up a special OpenStack@Cisco gift while supplies last.  Cisco specialists in services, sales and product development will be available to chat and answer any questions.

Mon. 03 Nov:  8:15 – 9:30 and 11:15 – 19:30
Tues. 04 Nov:  10:45 – 18:00
Wed. 05 Nov:  9:00 – 16:30

See demonstrations of:
-OpenStack Networking Using Cisco CSR and Nexus
-Cisco UCS Integrated Infrastructure with Red Hat OpenStack Platform
-Group-Based Policy for Cloud Deployment
-Cisco UCS Bare-Metal-as-a-Service Cloud

Metacloud Acquisition
Find out more about Metacloud, which officially became a part of Cisco on 17 SEP.  Metacloud offers OpenStack clouds as a service, giving customers a choice of hosted or hybrid architecture, to operate like a public cloud from inside an organization’s own data center.

Breakout: Group Based Policy Extension for Networking
Mon. 03 Nov; 16:20 – 17:00
Sumit Naiksatam, Principal Engineer, Cisco
https://openstacksummitnovember2014paris.sched.org/speaker/sumitnaiksatam#.VCXaM8Yac0s

Breakout: Deploying and Auto-Scaling Applications on OpenStack with Heat
Tues. 04 Nov; 11:15 – 11:55
Daneyon Hansen, Software Engineer, Cisco
https://openstacksummitnovember2014paris.sched.org/speaker/daneyonhansen#.VCXY7cYac0s

Panel Discussion: OpenStack Design Guide
Tues. 04 Nov; 14:00 – 14:40
Featuring: Maish Saidel-Keesing, Platform Architect, Cisco Video Technologies
https://openstacksummitnovember2014paris.sched.org/event/2345c8d9cfe52ebb104e860338dc2d7a#.VCXiAcYac0s

Panel Discussion: Tips and Tools for Building a Successful OpenStack Group
Tues. 04 Nov; 14:50-15:30
Featuring Shannon McFarland, Principal Engineer and Mark T. Voelker, Technical Lead; Cisco
https://openstacksummitnovember2014paris.sched.org/event/d1f8591a8436a656196478278fa83593#.VCXhGsYac0s

Breakout: Using Ceilometer Data to Detect Fraud in the OpenStack Cluster
Wed. 05 Nov; 9:50 – 10:30
Debojyoti Dutta, with Marc Solanas Tarre, Principal Engineers, Cisco
https://openstacksummitnovember2014paris.sched.org/speaker/dedutta#.VCXYSsYac0s

Breakout: Under the Hood with Nova, Libvirt and KVM (Part Two)
Wed. 05 Nov; 9:50 – 10:30
Rafi Khardalian, CTO, Metacloud/Cisco
https://openstacksummitnovember2014paris.sched.org/speaker/rkhardalian#.VCXZcMYac0s

Breakout: Scaling OpenStack Services: The Pre-TripleO Service Cloud
Wed. 05 Nov; 16:30 – 17:10
Kevin Bringard, with Richard Maynard
Technical Leads, Cisco
https://openstacksummitnovember2014paris.sched.org/speaker/kevinbringard1#.VCXXv8Yac0s

Evening Reception with Red Hat
Wed. 05 Nov; 20:00 – 2:00
Each attendee who completes the Red Hat and Cisco Booth Rally Challenge (instructions onsite) will receive a ticket for the Evening Reception held at Faust, an entertainment facility located at the foot of the Ivalides Esplanade, underneath the Alexandre III Bridge.  Shuttle transportation will be available.  Food and drinks will be served.  This is an awesome location and might very well be the highlight of the week.

RH Party











Tags: , , , , , , , ,

Cisco and OpenStack: Juno Release – Part 1

The next stable OpenStack release codenamed “Juno” is slated to be released October 16, 2014. From improving live upgrades in Nova to enabling easier migration from Nova Network to Neutron, the OpenStack Juno release will address operational challenges in addition to providing many new features and enhancements across all projects.

As indicated in the latest Stackalytics contributor statistics, Cisco has contributed to seven different OpenStack projects including Neutron, Cinder, Nova, Horizon and Ceilometer as part of the Juno development cycle. This is up from five projects in the Icehouse release. Cisco also ranks first in the number of completed blueprints in Neutron as well.

In this blog post, I’ll focus on Neutron contributions, which are the major share of contributions in Juno from Cisco.

blueprint_completed blueprint_completed_neutron

Cisco OpenStack team lead Neutron Community Contributions

An important blueprint that Cisco collaborated on and implemented with the community was to develop the Router Advertisement Daemon (radvd) for IPv6. With this support, multiple IPv6 configuration modes including SLAAC and DHCPv6 (both Stateful and Stateless modes) are now possible in Neutron. The implementation provides for running a radvd process in the router namespace for handling IPv6 auto address configuration.

To support the distributed routing model introduced by Distributed Virtual Router (DVR), this Firewall as a Service (FWaaS) blueprint implementation handles firewalling North–South traffic with DVR. The fix ensures that firewall rules are installed in the appropriate namespaces across the Network and Compute nodes to support perimeter firewall (North-South). However, firewalling East-West traffic with DVR will be handled in the next development cycle as a Distributed Firewall use case.

Additional capabilities in the ML2 and services framework were contributed for enabling better plugin and vendor driver integration. This included the following blueprint implementations -

Cisco device specific contributions in Neutron

Cisco added Application Policy Infrastructure Controller (APIC) ML2 MD and Layer 3 Service Plugin in the Juno development cycle. The ML2 APIC MD translates Neutron API calls into APIC data model specific requests and achieves tenant Layer 2 isolation through End-Point-Groups (EPG).

The APIC MD supports dynamic topology discovery using LLDP, reducing the configuration burden in Neutron for APIC MD and also ensures data is in-sync between Neutron and APIC. Additionally, the Layer 3 APIC service plugin enables configuration of internal and external subnet gateways on routers using Contracts to enable communication between EPGs as well as provide external connectivity. The APIC ML2 MD and Service Plugin have also been made available with OpenStack IceHouse release. Installation and Operation Guide for the driver and plugin is available here.

Enterprise-class virtual networking solution using Cisco Nexus1000v is enabled in OpenStack with its own core plugin. In addition to providing host based overlays using VxLAN (in both unicast and multi-cast mode), it provides Network and Policy Profile extensions for virtual machine policy provisioning.

The Nexus 1000v plugin added support for accepting REST API responses in JSON format from Virtual Supervisor Module (VSM) as well as control for enabling Policy Profile visibility across tenants. More information on features and how it integrates with OpenStack is provided here.

As an alternative to the default Layer 3 service implementations in Neutron, a Cisco router service plugin is now available that delivers Layer 3 services using the Cisco Cloud Services Router(CSR) 1000v.

The Cisco Router Service Plugin introduces a notion of “hosting device” to bind a Neutron router to a device that implements the router configuration. This allows the flexibility to add virtual as well as physical devices seamlessly into the framework for configuring services. Additionally, a Layer 3+ “configuration agent” is available upstream as well that interacts with the service plugin and is responsible for configuring the device for routing and advanced services.  The configuration agent is multi-service capable, supports configuration of hardware or software based L3 service devices via device drivers and also provides device health monitoring statistics.

The VPN as a Service (VPNaaS) driver using the CSR1000v has been available since the Icehouse release, as a proof-of-concept implementation. The Juno release enhances the CSR1000v VPN driver such that it can be used in a more dynamic, semi-automated manner to establish IPSec site-to-site connections, and paves the way for a fully integrated and dynamic implementation with the Layer 3 router plugin planned for the Kilo development cycle.

Summary

The OpenStack team at Cisco has led, implemented and successfully merged upstream numerous blueprints for the Neutron Juno release.  Clearly, some have been critical for the community and others enable customers to better integrate Cisco networking solutions with OpenStack Networking.

Stay tuned for more information on other project contributions in Juno and on Cisco lead sessions at the Kilo Summit in Paris !

You can also download OpenStack Cisco Validated Designs, White papers, and more at www.cisco.com/go/openstack

Tags: , , , , , , ,

OpenStack Gains Momentum with Users at Recent Summit

Cisco highlighted its support for OpenStack at the recent OpenStack Summit in Atlanta, which hosted 4500+ attendees and included many more users, in addition to the developers and operators that have dominated past conferences.  A common theme among keynote presentations was the speed and flexibility of IT required to support the clouds that will soon dominate commerce and communication worldwide.  The effort underway to improve stability was also a recurring discussion topic.

OpenStack Summit, May 12-15 in Atlanta

OpenStack Summit, May 12-15 in Atlanta

From its beginning as an open source project at NASA, the OpenStack movement has grown as an open alternative to propriety cloud services and applications.  The Summit serves as a forum for those interested in hashing out the direction and adoption of the model and standards, as well as a learning opportunity for those ready to build and deploy on them.

Keynote speakers from Wells Fargo and Disney helped transition the Summit from an academic exercise to a forum for learning how innovative companies are taking control of their cloud environments.

Glenn Ferguson, Head of Private Cloud Enablement for Wells Fargo, described the compliance, auditing and governance Wells requires in its private cloud, that aren’t available in public cloud offerings.  Wells has designated OpenStack their “cloud infrastructure model” to facilitate rapid deployment of infrastructure to meet application developers’ needs and requires all IT vendors to work within the OpenStack specifications. “This is something we have to do to remain agile and competitive in this environment,” Ferguson said.  “Our infrastructure needs to keep pace with the software.”

Chris Launey, Disney’s Director of Cloud Architectures and Services, was blunt in how he described the value of speed.  “If you’re a business that deals in any kind of information, you need speed (to thrive.)  “If you give (developers) their own ‘fast’, they’ll make their own ‘cheap’ by getting their product to market quickly and responding to customer demands.  And (they’ll) make their own ‘good’ by shrinking development cycles and introducing improvements more often, until they reach a virtual continuous cycle of improvements.”

The OpenStack Foundation divides the work into individual projects focused on the various cloud components: servers, object-based storage, networking infrastructure, security, etc.  Proponents are excited about the innovation that can be unleashed when developers are freed from having to worry about the complexities associated with underlying infrastructure and can focus on the innovation of cloud services and applications.

Cisco was highly visible at the Summit, drawing standing-room-only crowds to sessions in the Networking Track,  as network stability and scalability are top-of-mind for users deploying critical applications and services to an open source cloud.

Lew Tucker, Cisco Vice President and CTO for Cloud Computing and Vice-Chair of the OpenStack Foundation, painted a picture of what is possible in his presentation “Open Stack and the Transformation of the Data Center.”  He described how the data center is becoming a large, highly automated “fabric” consisting of interconnected physical systems and virtualized services.  In this environment, OpenStack acts as a platform for building a highly efficient cloud, providing management of diverse infrastructure “below” and orchestration of a vast set of application services “above”.

Lew Tucker, Cisco VP and CTO of Cloud Computing

Lew Tucker, Cisco VP and CTO of Cloud Computing

Cisco’s key contribution to OpenStack has been participation in the development of Neutron, the OpenStack Networking Service.  There is clearly a need to have the same level of visibility and management flexibility that Cisco has been offering its customers in an open source cloud model.  In addition to driving connectivity generally, Cisco has received approval on blueprints for plugins to integrate VPN- and Firewall-as-a-Service as part of OpenStack networking.  (Referred to as Network Function Virtualization (NFV) plugins.)  Cisco is also working on the integration of OpenStack Neutron with OpenDaylight, a separate project started to focus specifically on network programmability.  Cisco’s extensive work in the open source community will bring even greater value to its existing customers by extending the ecosystem of solutions integrated with Cisco products.

In the Expo Hall, Cisco highlighted the integration of its networking, compute and management products with OpenStack APIs, demonstrating:

If you missed the Summit, check out the Session Videos and Slides to deep-dive presentations by Cisco contributors, presented at the Atlanta Summit 2014:

Tags: , , , , , , , , ,

OpenDaylight Unleashes Hydrogen to the Masses

The OpenDaylight Project today announced that its first open source software release Hydrogen is now available for download. As the first simultaneous code release cross-community it has contributions across fifty organizations and includes over one million lines of code. Yes. ODL > 1MLOC. For those of you interested that’s approximately two hundred and thirty man-years of work completed in less than twelve months.

It was around this time last year that the media started to pick up on a few rumors that something may be in the works with software-defined networking and controllers. I remember our first meeting at Citrix where the community started to collaborate on The OpenDaylight Project and come to common ground on how to start something this large. We had multiple companies and academics in the room and many ideas of where we wanted this project to go but there was one thing we had in common: the belief and vision to drive networking software innovation to the Internet in a new way and accelerate SDN in the open; transparently and with diverse community support. Each of us had notions of what we could bring to the table, from controller offerings to virtualization solutions, SDN protocol plugins and apps to solve IT problems. Over two days at Citrix we looked at things from a customer perspective, a developer perspective and ultimately and arguably the most important, a community perspective. From there The OpenDaylight Project emerged under the Linux Foundation. As I look back I want to applaud and thank the companies, partners, developers, community members and the Linux Foundation for driving such a large vision from concept to reality in less than twelve months, which is an incredible feat in itself.

Hydrogen is truly a community release. Use cases span across enterprise, service provider, academia, data center, transport and NfV. There are multiple southbound protocols abstracted to a common northbound API for cross-vendor integration and interoperability and three editions have been created to ensure multi-domain support and application delivery as well as deployment modularity and flexibility for different domain-specific configurations. These packages have a consistent environment yet are tailored to domain and role-based needs of network engineers, developers and operators.

  • The Base Edition, which includes a scalable and multi-vendor SDN protocol based on OSGi, the latest (and backward compatible) OpenFlow 1.3 Plugin and Protocol Library, OVSDB, NetConf/Yang model driver SDN and Java-based YANG tooling for model-driven development.
  • The Virtualization Edition (which includes the Base Edition) and adds Affinity Metadata Service (essentially APIs to express workload relationships and service levels), Defense4All (DDoS detection & mitigation), Open DOVE, VTN, OpenStack Neutron NorthBound API support and a virtual tenant network offering.
  • The Service Provider Edition (again, including the Base Edition) that also offers the Metadata Services and Defense4All but includes BGP-LS and PCEP, LISP Flow Mapping and SNMP4SDN to manage routers, gateways switches.

More information can be found on the website with regards to the releases and projects themselves.

I want to stress the importance of how well the vision has been delivered to date. I’ve been involved in multiple standards-bodies and in open source discussions in the past but this is truly one of the largest undertakings I’ve seen come together in my entire career. OpenDaylight developers have been coding day and night to get this release out the door and it’s amazing to see the collaboration and coherency of the team as we unite to deliver on the industry’s first cross-vendor SDN and NfV Platform. In addition and frequently not mentioned is that many of the protocols listed in the Editions above are also standardized at organizations like the IETF during the same period. Code and specs at the same time. It’s been a long time since rough consensus and running code has been the norm.

Over here at Cisco we’re fully committed to OpenDaylight. We’re currently using it as a core component in our WAN Orchestration offering for service providers to allow intelligent network placement and automated capacity and workload planning. The ACI team (formerly Insieme) collaborated with IBM, Midokura and Plexxi to create a project in OpenDaylight that creates a northbound API that can set policy and be used across a wide range of network devices. And of course we’re bringing components of the OpenDaylight codebase into our own controllers and ensuring application portability for customers, partners and developers alike. From this I would expect to see more code donations going into the community moving forward as well. We made several announcements last week about our campus/branch controller that includes OpenDaylight technology.

At the end of the day an open source project is only as strong as its developers, its community and its code. As we as a community move forward with OpenDaylight I expect it to become stronger with more members joining with new project proposals as new code contributors coming onboard from different industries as well. As I look at our roadmap and upcoming release schedule I’m pumped for what’s next and so happy the community has catalyzed a developer community around networking.

Please do visit the site, download the code and take Hydrogen for a test-drive. We want to hear feedback on what we can make better, what features to add or how you’re going to utilize it. Moreover, we’d love you to participate. It’s a kick-ass community and I think you’ll have fun and the best part; you’ll see your hard work unleashed on the Internet and across multiple communities too.

Tags: , , , , , , , , , , , , , , , , , , ,

Speaking proposal submissions for OpenStack Summit – Voting is Open!

Cisco celebrated OpenStack’s 3rd birthday recently by releasing the Cisco OpenStack Installer for Grizzly. This blog post has more details.

The OpenStack foundation organizes a four-day OpenStack Summit every six months for contributors, enterprise users, service providers, application developers and ecosystem members. It facilitates the community to gather, discuss and present on several different streams ranging from keynote presentations and general sessions to workshops and developer sessions for planning the next OpenStack release. The next OpenStack Summit will be held in Hong Kong from November 5th to the 8th 2013 at the Asia World-Expo. The number of attendees for the Summit is expected to be around 5000 people.  More information on the Summit and how you can register to attend is available here.

Speaking proposals are submitted by the community from anyone with an idea or topic they would like to present. The proposals are voted on by the community to secure a slot in session track. Submissions for the OpenStack summit general sessions closed on July 31st 2013 and are now available for vote.

As compared to the Portland summit that had 250 proposal submissions [you can view session videos from OpenStack Portland Summit here, the Hong Kong summit has more than 600 submissions. There are a lot of great proposals but only the best and most popular will make it to the Summit. The approved sessions typically get recorded and are available for viewing online as well.

Cisco’s OpenStack team submitted several proposals that highlight our involvement and contributions to OpenStack. The table below lists the proposals along with a link to the abstract and speaker details.

Products & Services
Technical Deep Dive
Apps on OpenStack
Getting Started
Operations
Community Building
Workshops
Related OSS Projects

Community voting is open now and if you are interested in any (or all) of the above proposals, please vote for them here. The voting is open until Sunday, August 25th 2013. Please note that you do need to be an OpenStack Community member in order to vote; If you are not currently a member, you can easily register for membership via the OpenStack website.

Stay tuned for more updates, as we get closer to the OpenStack summit.
