The University of Nevada, Las Vegas (UNLV), founded in 1957, is located in the heart of showbiz industry in Las Vegas. The school offers higher education programs ranging from business, engineering, fine arts and music, and science, and professional schools such as dental medicine and law.
The school’s mascot, Hey Reb, was recently featured on Hulu’s “Behind the Mask,” and you may recognize the Southern Gym during the dance scene between Elvis Presley and Ann-Margret Olsson in the movie Viva Las Vegas.
With over 24,000 unique WLAN users per day, 1.1 gigabytes of throughput per second, and more than 50 wireless access locations across campus providing WLAN coverage, this educational institute demands a massive Wi-Fi network.
In the previous blog, we highlighted some of the Bonjour enhancements of the 7.5 software release and the deployment of Bonjour at St. Margaret’s Episcopal School, a K-12 school. In this blog, we will describe details about UNLVs WLAN deployment, how they use Bonjour services, and give you an insight into rapid pace of innovation necessary to support this technology in the education arena. Read More »
Tags: 11ac, access point, administrator, aireOS, AP, App, Apple, application, AVC, Bonjour, Cisco, cleanair, control, controller, deployment, EFT, EFT code, freeradius, granularity, High Availability, ip, location, network, openldap, policy, release, service, SSID, standby, Stateful Switch Over, sub-second, technology, UNLV, user group, vegas, visibility, VLAN, webgui, wi-fi, wifi, wlan
If you are an Enterprise IT Manager, this is a question that you must ask yourself if you are considering deploying 802.11ac for your enterprise wireless network. 802.11ac has some great benefits such as wirelike speed and being able to handle a high concentration of clients. However, there is more to consider when deploying 802.11ac. For instance, how do I handle RF interference now that 802.11ac support 80MHz channels? Will legacy devices such as 802.11g/a/n allow me to achieve the best performance that 802.11ac advertises? How can I ensure that my users get the best wireless performance when they roam across a building? And lastly, as more clients join the network, is my performance going to suffer? These are all valid concerns and are something that Cisco addresses with HDX. HDX is High Density Experience and is part of Cisco’s 802.11ac solution. We just wrapped up a 4 part blog series on HDX where we answer these questions:
- For Interference Mitigation, we have CleanAir for 80MHz Channels
- Getting the best performance out of your network even with legacy clients, we have ClientLink 3.0 Read More »
Tags: 11ac, 802.11ac, cleanair, competitor, deployment, gigabit, HDX, high density, interference mitigation, legacy client, Mhz, Miercom, network, performance, QoS, rf, technology, vendor, wi-fi, wifi, wireless, wlan
Bowdoin College is a liberal arts college based in the town of Brunswick, Maine. It houses 1839 students in about 100 buildings and offers 33 different majors and 4 minors. The Bowdoin IT Team are pioneering in nature as would be expected from the state whose motto, “Dirigo”, translates to “I lead”; adopting bleeding-edge best-in-class technologies to provide the optimal connected experience for students, faculty, staff and guests. This is counter-balanced with pragmatism in phasing the roll-out of these services.
This next generation pervasive WLAN network enables students to collaborate with each other anywhere on the campus and with the teachers in the classroom. In the previous blog in 2012, we described how Bowdoin upgraded to 3602 Access Points and used the innovative CleanAir technology tie-in with Event Driven Radio Resource Monitoring to optimize WLAN coverage. They also adopted the Cisco Prime and ISE 1.2 for manageability and consistent wired-wireless Policy respectively. In this blog, we will cover more details about the recent upgrade of the Wireless LAN Controller from the previous model WiSM to the new model 5760 and describe highlights of our conversation with Jason and Trevor about the WLAN deployment itself.
Read More »
Tags: bowdoin, Cisco, cleanair, college, customer, deployment, education, higher education, IPv6 in WLAN, IT, next-generation, roll-out, rollout, services, technology, university, wi-fi, wifi, wireless
Editor’s Note: This is the first of a four-part deep dive series into High Density Experience (HDX), Cisco’s latest solution suite designed for high density environments and next-generation wireless technologies. For more on Cisco HDX, visit www.cisco.com/go/80211ac.
CleanAir for 802.11ac: Why Spectrum Intelligence Still Matters
In wireless networking and communications, as with life, nothing good comes for free. It’s well known that the primary feature of the new IEEE 802.11ac amendment is support for an 80 MHz-wide channel. The benefit of an 80 MHz channel is the potential to double usable throughput in comparison to that of 802.11n using a 40 MHz wide channel.
However, what is less well known is that a wider RF channel is also more susceptible to interference. In other words, 802.11ac devices “hear more” than 802.11n devices, primarily due to the wider channel support. It should be noted that this is not a flaw in the 802.11ac amendment, it’s simply basic communications theory.
Nevertheless, there is far more to building an 802.11ac access point than simply meeting the standard. Not all 802.11ac access points perform equally without interference. But more importantly, not all 802.11ac access points perform well in the presence of interference.
Furthermore, there is far more to deploying High Density wireless LANs than only considering the performance of individual access points. Read More »
Tags: 11ac, 802.11ac, applications, apps, bandwidth, Cisco, cleanair, device, gigabit, HDX, high density, mobile, mobility, network, networking, spectrum intelligence, user experience, wi-fi, wifi, wireless
Cisco’s newest 802.11ac product, the Aironet 3700 Series Access Point is now orderable and shipping in the next few weeks. The AP 3700 features an integrated 11ac radio with a 4x4 architecture and Cisco’s High-Density Experience (HDX) Technology. HDX is a suite of features specific to the AP 3700 that delivers the best possible user experience, especially in high client density networks. HDX is enabled by a combination of hardware and software features on the AP 3700, features including:
- CleanAir 80 MHz – Interference detection and mitigation
- ClientLink 3.0 – RF link quality
- Smart Roam – Intelligent roaming handoff
- Turbo Performance – Performance with high client density
Aruba recently launched their 802.11ac access point, the AP-220 series, featuring a 3x3 design.
Miercom recently published a third-party evaluation of the performance between the AP 3702i and the AP-225. The report consists of a diverse range of test cases meant to gauge real-world performance of the access points. The tests include; multi-client performance, single client rate vs. range, performance in the presence of interference, and performance on reduced power. Here are some of the highlights from the report.
The AP 3700 performed very well in the multi-client performance test, thanks impart to HDX Turbo Performance. With 60 clients, the AP 3702i had a 6x performance advantage over the AP-225. The AP-225 struggled to serve all the clients and only mustered 40 Mbps total. The AP 3702i was able to transmit a healthy 236 Mbps, while maintaining fair throughput to each client.
The test consisted of 60 11ac clients, all associated to the 5 GHz radio. The clients used were 10 Dell E6430 laptops with Broadcom 4360 three spatial-stream chips, 20 Apple Macbook Air two spatial-stream laptops, and 30 Dell E6430 laptops with Intel 7260 two spatial-stream chips. Clients were setup in an open office environment surrounding the AP. Distances varied from 10’ to 50’.
Read More »
Tags: #80211ac, 11ac, 3x3, 3x3 design, 802.11ac, access point, AP under test, AP-225, apple macbook air, APUT, aruba, broadcom 4360 chip, Cisco, cleanair, ClientLink, dell E6430 laptop, GHz radio, gigabit, gigabit wireless, high density experience, interference detection, macbook air, mbps, Mhz, Miercom, multi-client, network, performance test, PoE+, reduced power, report, third-party evaluation, wi-fi, wi-fi testing, wifi, wireless
