ITD: Load Balancing, Traffic Steering & Clustering using Nexus 5k/6k/7k/9k

Cisco Intelligent Traffic Director (ITD) is an innovative solution to bridge the performance gap between a multi-terabit switch and gigabit servers and appliances. It is a hardware based multi-terabit layer 4 load-balancing, traffic steering and clustering solution on the Nexus 5k/6k/7k/9k series of switches.

It allows customers to deploy servers and appliances from any vendor with no network or topology changes. With a few simple configuration steps on a Cisco Nexus switch, customers can create an appliance or server cluster and deploy multiple devices to scale service capacity with ease. The servers or appliances do not have to be directly connected to the Cisco Nexus switch.

ITD won the Best of Interop 2015 in Data Center Category.

With our patent pending innovative algorithms, ITD (Intelligent Traffic Director) supports IP-stickiness, resiliency, consistent hash, exclude access-list, NAT (EFT), VIP, health monitoring, sophisticated failure handling policies, N+M redundancy, IPv4, IPv6, VRF, weighted load-balancing, bi-directional flow-coherency, and IPSLA probes including DNS. There is no service module or external appliance needed. ITD provides order of magnitude CAPEX and OPEX savings for the customers. ITD is much superior than legacy solutions like PBR, WCCP, ECMP, port-channel, layer-4 load-balancer appliances.

ITD provides :

  1. Hardware based multi-terabit/s L3/L4 load-balancing at wire-speed.
  2. Zero latency load-balancing.
  3. CAPEX savings : No service module or external L3/L4 load-balancer needed. Every Nexus port can be used as load-balancer.
  4. Redirect line-rate traffic to any devices, for example web cache engines, Web Accelerator Engines (WAE), video-caches, etc.
  5. Capability to create clusters of devices, for example, Firewalls, Intrusion Prevention System (IPS), or Web Application Firewall (WAF), Hadoop cluster
  6. IP-stickiness
  7. Resilient (like resilient ECMP), Consistent hash
  8. VIP based L4 load-balancing
  9. NAT (available for EFT/PoC). Allows non-DSR deployments.
  10. Weighted load-balancing
  11. Load-balances to large number of devices/servers
  12. ACL along with redirection and load balancing simultaneously.
  13. Bi-directional flow-coherency. Traffic from A–>B and B–>A goes to same node.
  14. Order of magnitude OPEX savings : reduction in configuration, and ease of deployment
  15. Order of magnitude CAPEX savings : Wiring, Power, Rackspace and Cost savings
  16. The servers/appliances don’t have to be directly connected to Nexus switch
  17. Monitoring the health of servers/appliances.
  18. N + M redundancy.
  19. Automatic failure handling of servers/appliances.
  20. VRF support, vPC support, VDC support
  21. Supported on all linecards of Nexus 9k/7k/6k/5k series.
  22. Supports both IPv4 and IPv6
  23. Cisco Prime DCNM Support
  24. exclude access-list
  25. No certification, integration, or qualification needed between the devices and the Cisco NX-OS switch.
  26. The feature does not add any load to the supervisor CPU.
  27. ITD uses orders of magnitude less hardware TCAM resources than WCCP.
  28. Handles unlimited number of flows.

For example,

  • Load-balance traffic to 256 servers of 10Gbps each.
  • Load-balance to cluster of Firewalls. ITD is much superior than PBR.
  • Scale IPS, IDS and WAF by load-balancing to standalone devices.
  • Scale the NFV solution by load-balancing to low cost VM/container based NFV.
  • Scale the WAAS / WAE solution.
  • Scale the VDS-TC (video-caching) solution.
  • Scale the Layer-7 load-balancer, by distributing traffic to L7 LBs.
  • ECMP/Port-channel cause re-hashing of flows. ITD is resilient, and doesn’t cause re-hashing on node add/delete/failure.

Documentation, slides, videos:

Email Query or

Please note that ITD is not a replacement for Layer-7 load-balancer (URL, cookies, SSL, etc). Please email: for further questions.

Connect on twitter: @samar4

Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

ITD Deployment with Transparent mode security devices

ITD (Intelligent Traffic Director) is getting a lot of interest about transparent (Layer 2) mode device support.

Here is a 10 minute video that shows step by step ITD deployment for Transparent mode security devices, such as Firewalls, IPS, IDS, Web application Firewalls (WAF), ASA, Cisco Sourcefire, etc:

ITD is a hardware based multi-Tbps Layer 4 load-balancing, traffic steering and clustering solution on Nexus 5k/6k/7k/9k series of switches. It supports IP-stickiness, resiliency, NAT (EFT), VIP, health monitoring, sophisticated failure handling policies, N+M redundancy, IPv4, IPv6, VRF, weighted load-balancing, bi-directional flow-coherency, and IPSLA probes including DNS. There is no service module or external appliance needed.

Solution Guide: ITD with Layer 2 Firewall / IPS / IDS

Here is more information about ITD:

Please send email to if you have any questions.


Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Like Chalk and Cheese: Cisco ASA 5506-X with Release 9.4.1 – Policy Based Routing

Cisco ASA 5506-XEarlier this Year, Cisco introduced the Cisco ASA 5506-X with FirePOWER Services. This Model should replace the successful and smallest Security Solution, the ASA 5505. Designed for the Small Business and a new era of threat and advanced malware protection Cisco ASA with FirePOWER Services delivers an integrated threat defense for the entire attack continuum. BEFORE, DURING and AFTER.

As Desktop version, the Cisco ASA 5506-X builds an easy entry for a:


Cisco ASA 5506-X 1

  •  Superior Multilayered Protection
    • Site-to-site and remote access VPN
    • Granular Application Visibility and Control (AVC)
    • Highly effective threat prevention and full contextual awareness
    • Reputation- and category-based URL filtering
    • AMP provides industry-leading breach detection effectiveness
  • Unprecedented Network Visbility
  • Reduced Costs and Complexity security Solution

Read More »

Tags: , , , , , , , , , , , , ,

Cisco brings proven ASA security to AWS marketplace customers

We are very excited to announce the availability of Cisco’s best-selling Cisco Adaptive Security Virtual Appliance (ASAv) for the Amazon Web Services (AWS) cloud platform.

Our customers can now use Cisco ASAv to protect their on-demand AWS workloads and achieve consistency across hybrid cloud environments. The Cisco Adaptive Security Virtual Appliance (ASAv) runs the same software as physical Cisco ASAs to deliver proven security functionality in a virtual form factor.

Cisco ASAv on the AWS Marketplace offers: Read More »

Tags: , , ,

Plan to Be Secure; Secure to Your Plan

The routine goes something like this. First a breach of security occurs somewhere in the enterprise, it could be something as small as a single computer getting infected or it could be a massive data loss. It seems like that’s a wide range of events, but often the reaction in an enterprise is the same. The IT executives have a meeting to determine fault and then the analysts and engineers are given the task of making sure that that particular incident never happens again. The analysts and engineers then reply with budget requests for new software and hardware from their favorite vendors. Unfortunately the end result is generally that money is spent and security is only moderately improved, if at all.

In the midst of reacting, everyone forgets that technology doesn’t configure itself and that the weakest link are the people. Instead of ramming in the latest and greatest in technology, we should be leading our company to review, create (if necessary) and rewrite our security policies. Without a policy, security tools are like unguided missiles that we hope hit their target. Read More »
